Details
- •Low-voltage industrial components
- •Motor starter/motor starter combination
- •1 KOM
- •EATON
Technical specifications
Width90mm
With transformerNo
Height123.4mm
Power consumption0.9W
Rated operation power at AC-3, 400 V5.5kW
Depth228mm
Number of auxiliary contacts as normally closed contact0
Overload release current setting8 - 12A
Number of indicator lights0
Number of auxiliary contacts as normally open contact0
Suitable for emergency stopNo
Number of command positions0
Rated operation current Ie11.3A
Supporting protocol for LONNo
Supporting protocol for INTERBUSNo
Supporting protocol for ModbusNo
Supporting protocol for CANNo
Supporting protocol for Data-HighwayNo
Supporting protocol for ASINo
Supporting protocol for PROFIBUSNo
Supporting protocol for TCP/IPNo
Supporting protocol for DeviceNetNo
Rated control supply voltage Us at AC 60HZ0 - 0V
Supporting protocol for other bus systemsNo
Supporting protocol for SUCONETNo
Rated control supply voltage Us at DC24 - 24V
External reset possibleNo
Rail mounting possibleNo
Degree of protection (IP)IP00
Rated control supply voltage Us at AC 50HZ0 - 0V
Type of electrical connection for auxiliary- and control current circuitScrew connection
Supporting protocol for INTERBUS-SafetyNo
Supporting protocol for SERCOSNo
Type of electrical connection of main circuitScrew connection
Supporting protocol for AS-Interface Safety at WorkNo
Release classCLASS 10 A
With fuseNo
With short-circuit releaseYes
Supporting protocol for EtherNet/IPNo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for PROFINET CBANo
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for PROFINET IONo
Supporting protocol for SafetyBUS pNo
Type of motor starterReversing starter
Voltage type for actuatingDC
Supporting protocol for PROFIsafeNo
Ambient temperature, upper operating limit55°C
Rated operation power at AC-3, 230 V, 3-phase3kW
Rated power, 460 V, 60 Hz, 3-phase0kW
Rated power, 575 V, 60 Hz, 3-phase0kW
Rated operation current at AC-3, 400 V12A
Rated conditional short-circuit current, type 2, 230 V50000A
Temperature compensated overload protectionYes
Rated conditional short-circuit current, type 2, 400 V50000A
Rated conditional short-circuit current, type 1, 480 Y/277 V0A
Degree of protection (NEMA)Other
Coordination class according to IEC 60947-4-3Class 2
Rated conditional short-circuit current, type 1, 600 Y/347 V0A
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
MSC-R-12-M17(24VDC)
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Motor starter/motor starter combination
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Width
90mm
With transformer
Height
123.4mm
Power consumption
0.9W
Rated operation power at AC-3, 400 V
5.5kW
Depth
228mm
Number of auxiliary contacts as normally closed contact
0
Overload release current setting
8 .. 12A
Number of indicator lights
0
Number of auxiliary contacts as normally open contact
0
Suitable for emergency stop
Number of command positions
0
Rated operation current Ie
11.3A
Supporting protocol for LON
Supporting protocol for INTERBUS
Supporting protocol for Modbus
Supporting protocol for CAN
Supporting protocol for Data-Highway
Supporting protocol for ASI
Supporting protocol for PROFIBUS
Supporting protocol for TCP/IP
Supporting protocol for DeviceNet
Rated control supply voltage Us at AC 60HZ
0 .. 0V
Supporting protocol for other bus systems
Supporting protocol for SUCONET
Rated control supply voltage Us at DC
24 .. 24V
External reset possible
Rail mounting possible
Degree of protection (IP)
IP00
Rated control supply voltage Us at AC 50HZ
0 .. 0V
Type of electrical connection for auxiliary- and control current circuit
Screw connection
Supporting protocol for INTERBUS-Safety
Supporting protocol for SERCOS
Type of electrical connection of main circuit
Screw connection
Supporting protocol for AS-Interface Safety at Work
Release class
CLASS 10 A
With fuse
With short-circuit release
Supporting protocol for EtherNet/IP
Supporting protocol for Foundation Fieldbus
Supporting protocol for PROFINET CBA
Supporting protocol for DeviceNet Safety
Supporting protocol for PROFINET IO
Supporting protocol for SafetyBUS p
Type of motor starter
Reversing starter
Voltage type for actuating
DC
Supporting protocol for PROFIsafe
Ambient temperature, upper operating limit
55°C
Rated operation power at AC-3, 230 V, 3-phase
3kW
Rated power, 460 V, 60 Hz, 3-phase
0kW
Rated power, 575 V, 60 Hz, 3-phase
0kW
Rated operation current at AC-3, 400 V
12A
Rated conditional short-circuit current, type 2, 230 V
50000A
Temperature compensated overload protection
Rated conditional short-circuit current, type 2, 400 V
50000A
Rated conditional short-circuit current, type 1, 480 Y/277 V
0A
Degree of protection (NEMA)
Other
Coordination class according to IEC 60947-4-3
Class 2
Rated conditional short-circuit current, type 1, 600 Y/347 V
0A
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
