FAZ-B10/1N
Code: 1047203
ManufacturerEaton
Catalog number278644
TypeFAZ-B10/1N
CategoryMiniature circuit breaker (MCB)
EAN code4015082786441
Details
- •Circuit breaker FAZ, char B, 1+N-pole, In=10A
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •Minimum order quantity: 1 pcs
- •EATON
Technical specifications
Voltage typeAC
Over voltage category3
Concurrently switching neutral conductorYes
Connectable conductor cross section solid-core1 - 25mm²
Degree of protection (IP)IP20
Rated insulation voltage Ui440V
Number of protected poles1
Rated voltage230V
Explosion-proofNo
Width in number of modular spacings2
Frequency50 - 60Hz
Connectable conductor cross section multi-wired1 - 25mm²
Ambient temperature during operating-25 - 75°C
Built-in depth70.5mm
Power loss2W
Current limiting class3
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V15kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Additional equipment possibleYes
Flush-mounted installationNo
Pollution degree2
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V15kA
Rated impulse withstand voltage Uimp4kV
Rated current10A
Release characteristicB
Number of poles (total)2
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
