FAZ-C4/3
Code: 1047310
ManufacturerEaton
Catalog number278865
TypeFAZ-C4/3
CategoryMiniature circuit breaker (MCB)
EAN code4015082788650
Details
- •Circuit breaker FAZ, char C, 3-pole, In=4A, I
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •Minimum order quantity: 1 pcs
- •EATON
Technical specifications
Voltage typeAC
Built-in depth70.5mm
Over voltage category3
Rated voltage400V
Power loss4.5W
Frequency50 - 60Hz
Concurrently switching neutral conductorNo
Rated insulation voltage Ui440V
Degree of protection (IP)IP20
Ambient temperature during operating-25 - 75°C
Flush-mounted installationNo
Explosion-proofNo
Current limiting class3
Connectable conductor cross section solid-core1 - 25mm²
Pollution degree2
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V15kA
Connectable conductor cross section multi-wired1 - 25mm²
Rated impulse withstand voltage Uimp4kV
Width in number of modular spacings3
Number of protected poles3
Additional equipment possibleYes
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V15kA
Rated current4A
Release characteristicC
Number of poles (total)3
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
