FAZ-K2/3
Code: 1047332
Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •EATON
Technical specifications
Built-in depth70.5mm
Rated current2A
Release characteristicK
Number of poles (total)3
Rated voltage400V
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V0kA
Current limiting class3
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V10kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V0kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V10kA
Rated impulse withstand voltage Uimp4kV
Flush-mounted installationNo
Over voltage category3
Additional equipment possibleYes
Power loss4.3W
Frequency50 - 60Hz
Rated insulation voltage Ui440V
Concurrently switching neutral conductorNo
Voltage typeAC
Width in number of modular spacings3
Degree of protection (IP)IP20
Ambient temperature during operating-25 - 75°C
Pollution degree2
Connectable conductor cross section multi-wired1 - 25mm²
Explosion-proofNo
Connectable conductor cross section solid-core1 - 25mm²
Number of protected poles3
