FAZ-B13/3N
Code: 1047359
Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •EATON
Technical specifications
Release characteristicB
Built-in depth70.5mm
Rated current13A
Number of protected poles3
Rated insulation voltage Ui440V
Rated voltage400V
Number of poles (total)4
Voltage typeAC
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V15kA
Frequency50 - 60Hz
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Flush-mounted installationNo
Rated impulse withstand voltage Uimp4kV
Concurrently switching neutral conductorYes
Over voltage category3
Current limiting class3
Pollution degree2
Power loss8.1W
Additional equipment possibleYes
Connectable conductor cross section multi-wired1 - 25mm²
Connectable conductor cross section solid-core1 - 25mm²
Width in number of modular spacings4
Explosion-proofNo
Degree of protection (IP)IP20
Ambient temperature during operating-25 - 75°C
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V15kA
