FAZ-B40/4
Code: 1047413
Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •EATON
Technical specifications
Rated voltage400V
Release characteristicB
Number of poles (total)4
Number of protected poles4
Rated current40A
Built-in depth70.5mm
Rated insulation voltage Ui440V
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V15kA
Voltage typeAC
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
Flush-mounted installationNo
Current limiting class3
Connectable conductor cross section solid-core1 - 25mm²
Concurrently switching neutral conductorYes
Additional equipment possibleYes
Over voltage category3
Power loss11.6W
Degree of protection (IP)IP20
Width in number of modular spacings4
Pollution degree2
Frequency50 - 60Hz
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V15kA
Ambient temperature during operating-25 - 75°C
Explosion-proofNo
Connectable conductor cross section multi-wired1 - 25mm²
