FAZ-C6/1-DC
Code: 1047458
Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •EATON
Technical specifications
Number of protected poles1
Rated current6A
Rated voltage250V
Release characteristicC
Rated insulation voltage Ui440V
Voltage typeDC
Rated impulse withstand voltage Uimp4kV
Built-in depth70.5mm
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V0kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V10kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V0kA
Frequency50 - 60Hz
Power loss1.2W
Current limiting class3
Flush-mounted installationNo
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V10kA
Pollution degree2
Concurrently switching neutral conductorNo
Additional equipment possibleYes
Over voltage category3
Degree of protection (IP)IP20
Explosion-proofNo
Connectable conductor cross section multi-wired1 - 25mm²
Ambient temperature during operating-25 - 75°C
Connectable conductor cross section solid-core1 - 25mm²
Width in number of modular spacings1
Number of poles (total)1
