AZ-C20
Code: 1047570
Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •EATON
Technical specifications
Number of poles (total)1
Release characteristicC
Number of protected poles1
Built-in depth75mm
Rated impulse withstand voltage Uimp4kV
Rated insulation voltage Ui440V
Rated current20A
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V0kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V0kA
Rated voltage230V
Concurrently switching neutral conductorNo
Flush-mounted installationNo
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V25kA
Frequency50 - 60Hz
Pollution degree2
Additional equipment possibleYes
Over voltage category3
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V25kA
Degree of protection (IP)IP20
Current limiting class3
Connectable conductor cross section multi-wired2.5 - 50mm²
Explosion-proofNo
Connectable conductor cross section solid-core2.5 - 50mm²
Ambient temperature during operating-25 - 55°C
Voltage typeAC
Width in number of modular spacings1.5
