Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •EATON
Technical specifications
Voltage typeAC
Degree of protection (IP)IP20
Connectable conductor cross section solid-core2.5 - 50mm²
Rated current100A
Frequency50 - 60Hz
Rated insulation voltage Ui440V
Concurrently switching neutral conductorNo
Explosion-proofNo
Connectable conductor cross section multi-wired2.5 - 50mm²
Additional equipment possibleYes
Width in number of modular spacings3
Over voltage category3
Flush-mounted installationNo
Release characteristicC
Number of protected poles2
Built-in depth75mm
Current limiting class3
Ambient temperature during operating-25 - 55°C
Rated voltage400V
Pollution degree2
Number of poles (total)2
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V0kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V20kA
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V0kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V20kA
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
AZ-2-C100
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Miniature circuit breaker (MCB)
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Voltage type
AC
Degree of protection (IP)
IP20
Connectable conductor cross section solid-core
2.5 .. 50mm²
Rated current
100A
Frequency
50 .. 60Hz
Rated insulation voltage Ui
440V
Concurrently switching neutral conductor
Explosion-proof
Connectable conductor cross section multi-wired
2.5 .. 50mm²
Additional equipment possible
Width in number of modular spacings
3
Over voltage category
3
Flush-mounted installation
Release characteristic
C
Number of protected poles
2
Built-in depth
75mm
Current limiting class
3
Ambient temperature during operating
-25 .. 55°C
Rated voltage
400V
Pollution degree
2
Number of poles (total)
2
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
0kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
20kA
Rated impulse withstand voltage Uimp
4kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
0kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
20kA
