Details
- •Low-voltage industrial components
- •Power contactor, AC switching
- •1 KOM
- •EATON
Technical specifications
Width45mm
Height58mm
Depth54mm
Number of auxiliary contacts as normally open contact0
Rated operation power at AC-3, 400 V4kW
Number of normally open contacts as main contact3
Number of normally closed contacts as main contact0
Modular versionNo
Rated control supply voltage Us at AC 60HZ0 - 0V
Rated operation current Ie at AC-1, 400 V22A
Rated control supply voltage Us at DC110 - 110V
Voltage type for actuatingDC
Number of auxiliary contacts as normally closed contact1
Rated operation current Ie at AC-3, 400 V9A
Rated control supply voltage Us at AC 50HZ0 - 0V
Rated operation power at AC-4, 400 V3kW
Rated operation power NEMA3.7kW
Operating voltage at AC 60 Hz24 - 690V
Rated operation current Ie at AC-4, 400 V6.6A
Type of electrical connection of main circuitSpring clamp connection
Operating voltage at AC 50 Hz24 - 690V
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
DILEM-01-G-C(110VDC)
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power contactor, AC switching
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Width
45mm
Height
58mm
Depth
54mm
Number of auxiliary contacts as normally open contact
0
Rated operation power at AC-3, 400 V
4kW
Number of normally open contacts as main contact
3
Number of normally closed contacts as main contact
0
Modular version
Rated control supply voltage Us at AC 60HZ
0 .. 0V
Rated operation current Ie at AC-1, 400 V
22A
Rated control supply voltage Us at DC
110 .. 110V
Voltage type for actuating
DC
Number of auxiliary contacts as normally closed contact
1
Rated operation current Ie at AC-3, 400 V
9A
Rated control supply voltage Us at AC 50HZ
0 .. 0V
Rated operation power at AC-4, 400 V
3kW
Rated operation power NEMA
3.7kW
Operating voltage at AC 60 Hz
24 .. 690V
Rated operation current Ie at AC-4, 400 V
6.6A
Type of electrical connection of main circuit
Spring clamp connection
Operating voltage at AC 50 Hz
24 .. 690V
