Details
- •Low-voltage industrial components
- •Power contactor, AC switching
- •1 KOM
- •EATON
Technical specifications
Number of normally open contacts as main contact3
Number of normally closed contacts as main contact0
Modular versionNo
Rated operation power at AC-3, 400 V37kW
Rated control supply voltage Us at AC 60HZ240 - 240V
Number of auxiliary contacts as normally closed contact2
Rated operation current Ie at AC-3, 400 V80A
Number of auxiliary contacts as normally open contact2
Rated control supply voltage Us at AC 50HZ230 - 230V
Rated operation current Ie at AC-1, 400 V110A
Type of electrical connection of main circuitScrew connection
Rated operation power NEMA44.7kW
Rated control supply voltage Us at DC0 - 0V
Rated operation current Ie at AC-4, 400 V40A
Rated operation power at AC-4, 400 V20kW
Voltage type for actuatingAC
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
DILM80-22(230V50HZ,240V60HZ)
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power contactor, AC switching
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Number of normally open contacts as main contact
3
Number of normally closed contacts as main contact
0
Modular version
Rated operation power at AC-3, 400 V
37kW
Rated control supply voltage Us at AC 60HZ
240 .. 240V
Number of auxiliary contacts as normally closed contact
2
Rated operation current Ie at AC-3, 400 V
80A
Number of auxiliary contacts as normally open contact
2
Rated control supply voltage Us at AC 50HZ
230 .. 230V
Rated operation current Ie at AC-1, 400 V
110A
Type of electrical connection of main circuit
Screw connection
Rated operation power NEMA
44.7kW
Rated control supply voltage Us at DC
0 .. 0V
Rated operation current Ie at AC-4, 400 V
40A
Rated operation power at AC-4, 400 V
20kW
Voltage type for actuating
AC
