Details
- •Low-voltage industrial components
- •Power contactor, AC switching
- •1 KOM
- •EATON
Technical specifications
Rated control supply voltage Us at DC24 - 24V
Number of auxiliary contacts as normally open contact2
Rated operation power at AC-3, 400 V4kW
Number of normally closed contacts as main contact0
Rated control supply voltage Us at AC 60HZ0 - 0V
Rated control supply voltage Us at AC 50HZ0 - 0V
Modular versionNo
Number of normally open contacts as main contact3
Rated operation current Ie at AC-3, 400 V9A
Number of auxiliary contacts as normally closed contact1
Rated operation current Ie at AC-1, 400 V22A
Voltage type for actuatingDC
Rated operation current Ie at AC-4, 400 V6A
Type of electrical connection of main circuitScrew connection
Rated operation power at AC-4, 400 V2.5kW
Rated operation power NEMA3.7kW
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
DILM9-21(24VDC)
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power contactor, AC switching
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Rated control supply voltage Us at DC
24 .. 24V
Number of auxiliary contacts as normally open contact
2
Rated operation power at AC-3, 400 V
4kW
Number of normally closed contacts as main contact
0
Rated control supply voltage Us at AC 60HZ
0 .. 0V
Rated control supply voltage Us at AC 50HZ
0 .. 0V
Modular version
Number of normally open contacts as main contact
3
Rated operation current Ie at AC-3, 400 V
9A
Number of auxiliary contacts as normally closed contact
1
Rated operation current Ie at AC-1, 400 V
22A
Voltage type for actuating
DC
Rated operation current Ie at AC-4, 400 V
6A
Type of electrical connection of main circuit
Screw connection
Rated operation power at AC-4, 400 V
2.5kW
Rated operation power NEMA
3.7kW
Related products
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
