Details
- •Sensors
- •End switch
- •1 KOM
- •EATON
Technical specifications
Explosion safety category for gasNone
Suitable for safety functionsYes
With status indicationNo
Coating housingOther
Type of control elementNone
Number of safety auxiliary contacts1
Material housingPlastic
Explosion safety category for dustNone
Rated operation current Ie at AC-15, 230 V6A
Type of electric connectionCable entry metrical
Forced openingYes
Switching functionSlow-action switch
Construction type housingCuboid
Type of interface for safety communicationNone
Rated operation current Ie at DC-13, 230 V0.3A
Number of contacts as change-over contact0
Rated operation current Ie at AC-15, 24 V6A
Type of interfaceNone
Length of sensor39mm
Output electronicNo
Alignment of the control elementOther
Diameter sensor0mm
Rated operation current Ie at DC-13, 24 V3A
Number of contacts as normally closed contact1
Ambient temperature during operating-25 - 70°C
Rated operation current Ie at DC-13, 125 V0.8A
Degree of protection (NEMA)Other
Rated operation current Ie at AC-15, 125 V6A
Number of contacts as normally open contact1
Switching function latchingNo
Degree of protection (IP)IP65
Width sensor60mm
Height of sensor173mm
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
LS-S11-24DMT-ZBZ/X
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- End switch
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Explosion safety category for gas
None
Suitable for safety functions
With status indication
Coating housing
Other
Type of control element
None
Number of safety auxiliary contacts
1
Material housing
Plastic
Explosion safety category for dust
None
Rated operation current Ie at AC-15, 230 V
6A
Type of electric connection
Cable entry metrical
Forced opening
Switching function
Slow-action switch
Construction type housing
Cuboid
Type of interface for safety communication
None
Rated operation current Ie at DC-13, 230 V
0.3A
Number of contacts as change-over contact
0
Rated operation current Ie at AC-15, 24 V
6A
Type of interface
None
Length of sensor
39mm
Output electronic
Alignment of the control element
Other
Diameter sensor
0mm
Rated operation current Ie at DC-13, 24 V
3A
Number of contacts as normally closed contact
1
Ambient temperature during operating
-25 .. 70°C
Rated operation current Ie at DC-13, 125 V
0.8A
Degree of protection (NEMA)
Other
Rated operation current Ie at AC-15, 125 V
6A
Number of contacts as normally open contact
1
Switching function latching
Degree of protection (IP)
IP65
Width sensor
60mm
Height of sensor
173mm
