Details
- •Sensors
- •End switch
- •1 KOM
- •EATON
Technical specifications
Rated operation current Ie at AC-15, 230 V6A
Rated operation current Ie at DC-13, 230 V0.3A
Switching functionQuick-break switch
Type of interface for safety communicationNone
Suitable for safety functionsYes
With status indicationNo
Material housingPlastic
Type of electric connectionCable entry metrical
Coating housingOther
Degree of protection (IP)IP66/IP67
Type of control elementActuating rod
Explosion safety category for gasNone
Type of interfaceNone
Number of safety auxiliary contacts1
Explosion safety category for dustNone
Construction type housingCuboid
Rated operation current Ie at DC-13, 24 V3A
Width sensor31mm
Rated operation current Ie at DC-13, 125 V0.8A
Rated operation current Ie at AC-15, 125 V6A
Rated operation current Ie at AC-15, 24 V6A
Diameter sensor0mm
Height of sensor61mm
Output electronicNo
Switching function latchingNo
Number of contacts as normally open contact1
Forced openingYes
Length of sensor33.5mm
Degree of protection (NEMA)Other
Alignment of the control elementRoller cam crossed
Ambient temperature during operating-25 - 70°C
Number of contacts as normally closed contact1
Number of contacts as change-over contact0
