Details
- •Low-voltage industrial components
- •Power contactor, AC switching
- •1 KOM
- •EATON
Technical specifications
Modular versionNo
Width515mm
Depth252mm
Height392mm
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact3
Rated operation power at AC-3, 400 V0kW
Rated control supply voltage Us at AC 50HZ230 - 250V
Rated operation current Ie at AC-1, 400 V2700A
Rated operation current Ie at AC-3, 400 V0A
Rated control supply voltage Us at DC230 - 250V
Rated control supply voltage Us at AC 60HZ230 - 250V
Operating voltage at AC 60 Hz230 - 250V
Number of auxiliary contacts as normally closed contact2
Operating voltage at AC 50 Hz230 - 250V
Type of electrical connection of main circuitRail connection
Number of auxiliary contacts as normally open contact2
Rated operation power at AC-4, 400 V0kW
Voltage type for actuatingAC/DC
Rated operation power NEMA0kW
Rated operation current Ie at AC-4, 400 V0A
