Details
- •Low-voltage industrial components
- •Power contactor, AC switching
- •1 KOM
- •EATON
Technical specifications
Depth97mm
Rated operation power at AC-3, 400 V11kW
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact4
Width58mm
Number of auxiliary contacts as normally open contact1
Rated operation current Ie at AC-3, 400 V25A
Modular versionNo
Number of auxiliary contacts as normally closed contact0
Rated operation power at AC-4, 400 V7kW
Rated operation current Ie at AC-1, 400 V45A
Rated operation power NEMA11kW
Rated operation current Ie at AC-4, 400 V15A
Operating voltage at AC 50 Hz24 - 690V
Voltage type for actuatingAC
Rated control supply voltage Us at AC 60HZ240 - 240V
Rated control supply voltage Us at AC 50HZ230 - 230V
Rated control supply voltage Us at DC0 - 0V
Type of electrical connection of main circuitScrew connection
Operating voltage at AC 60 Hz24 - 690V
Height85mm
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
DILMP45-10(230V50HZ,240V60HZ)
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power contactor, AC switching
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Depth
97mm
Rated operation power at AC-3, 400 V
11kW
Number of normally closed contacts as main contact
0
Number of normally open contacts as main contact
4
Width
58mm
Number of auxiliary contacts as normally open contact
1
Rated operation current Ie at AC-3, 400 V
25A
Modular version
Number of auxiliary contacts as normally closed contact
0
Rated operation power at AC-4, 400 V
7kW
Rated operation current Ie at AC-1, 400 V
45A
Rated operation power NEMA
11kW
Rated operation current Ie at AC-4, 400 V
15A
Operating voltage at AC 50 Hz
24 .. 690V
Voltage type for actuating
AC
Rated control supply voltage Us at AC 60HZ
240 .. 240V
Rated control supply voltage Us at AC 50HZ
230 .. 230V
Rated control supply voltage Us at DC
0 .. 0V
Type of electrical connection of main circuit
Screw connection
Operating voltage at AC 60 Hz
24 .. 690V
Height
85mm
