Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Height245mm
Rated operating voltage690 - 690V
Number of switches1
Rated operation power at AC-3, 400 V0kW
Depth180mm
Number of auxiliary contacts as normally closed contact0
Rated permanent current Iu160A
Number of poles4
Width140mm
InterlockableYes
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as change-over contact0
Conditioned rated short-circuit current Iq0kA
Degree of protection (IP), front sideIP20
Version as maintenance-/service switchYes
Version as safety switchNo
Type of control elementRocker lever
Version as emergency stop installationYes
Colour control elementBlack
Type of electrical connection of main circuitScrew connection
Version as main switchYes
Rated short-time withstand current lcw3.5kA
Motor drive integratedNo
Rated operation power at AC-23, 400 V90kW
Suitable for front mounting 4-holeNo
Rated permanent current at AC-23, 400 V0A
Suitable for floor mountingYes
Suitable for intermediate mountingYes
Suitable for distribution board installationYes
Max. rated operation voltage Ue AC690V
Voltage release optionalYes
Motor drive optionalYes
Switching power at 400 V0kW
Suitable for front mounting centreNo
Rated permanent current at AC-21, 400 V0A
Version as reversing switchNo
Device constructionBuilt-in device plug-in technique
With pre-assembled cablingNo
Related products
