Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Built-in depth69.5mm
Rated current40A
Rated voltage230V
Voltage typeAC
Current limiting class3
Release characteristicB
Frequency50 Hz
Surge current capacity0.25kA
Rated short-circuit breaking capacity according to IEC 60947-20kA
Rated fault current0.03A
Number of protected poles1
Over voltage category3
Width in number of modular spacings2
Leakage current typeA
Concurrently switching neutral conductorYes
Degree of protection (IP)IP20
Pollution degree2
Rated insulation voltage Ui440V
Rated short-circuit breaking capacity according to EN 6100910kA
Rated impulse withstand voltage Uimp4kV
Number of poles (total)2
Rated short-circuit breaking capacity Icn according to EN 61009-110kA
Connectable conductor cross section solid-core1 - 25mm²
Suitable for flush-mounted installationNo
Ambient temperature during operating-25 - 40°C
Connectable conductor cross section multi-wired1 - 25mm²
Anti-nuisance tripping versionNo
With interlocking deviceNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
PFL7-40/1N/B/003-A
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Earth leakage circuit breaker
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Built-in depth
69.5mm
Rated current
40A
Rated voltage
230V
Voltage type
AC
Current limiting class
3
Release characteristic
B
Frequency
50 Hz
Surge current capacity
0.25kA
Rated short-circuit breaking capacity according to IEC 60947-2
0kA
Rated fault current
0.03A
Number of protected poles
1
Over voltage category
3
Width in number of modular spacings
2
Leakage current type
A
Concurrently switching neutral conductor
Degree of protection (IP)
IP20
Pollution degree
2
Rated insulation voltage Ui
440V
Rated short-circuit breaking capacity according to EN 61009
10kA
Rated impulse withstand voltage Uimp
4kV
Number of poles (total)
2
Rated short-circuit breaking capacity Icn according to EN 61009-1
10kA
Connectable conductor cross section solid-core
1 .. 25mm²
Suitable for flush-mounted installation
Ambient temperature during operating
-25 .. 40°C
Connectable conductor cross section multi-wired
1 .. 25mm²
Anti-nuisance tripping version
With interlocking device
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
