Details
- •Cables
- •Data and communication cable
- •1 KOM
- •EATON
Technical specifications
UV resistantNo
Core identificationColour
Stranding elementNo
Diameter conductor1.35mm
Material core insulationPolyvinyl chloride (PVC)
Characteristic impedance100Ohm
Nominal voltage U24V
Conductor materialOther
Screen over strandingNone
Screen over stranding elementNone
Nominal cross section conductor0.23mm²
Material outer sheathPolyvinyl chloride (PVC)
CategoryOther
Colour outer sheathGreen
Drain wireNo
Number of cores8
Number of stranding elements0
Armouring/reinforcementNone
Conductor categoryClass 2 = stranded
Permitted cable outer temperature after assembling without vibration-30 - 105°C
Protective sheathOther
Permitted cable outer temperature during assembling/handling-10 - 105°C
Cable typeOther
With rodent protectionNo
StrandingOther
Conductor surfaceTinned
Outer diameter approx.17.5mm
Cable width approx.17.5mm
Low smoke (according to IEC 61034-2)No
Cable height approx.22mm
Reaction-to-fire class according to EN 13501-6None
Longitudinal water blocking cableNo
Radial water blocking cableNo
Oil resistant (according to EN 60811-404)No
Halogen free (according to IEC 60754-2)No
AWG size24
Euro class acidity according to EN 13501-6None
Euro class flaming droplets/particles according to EN 13501-6None
Suitable for underground installationNo
NVP value66.7%
Smoke development class according to EN 13501-6None
Cable geometryFlat
Min. permitted bending radius, moving application/free movement15mm
Specification material outer sheathOther
Min. permitted bending radius, stationary application/permanent installation7.5mm
Specification core insulationOther
Min. permitted bending radius, moving application with forced guidance15mm
Material reinforcementOther
Suitable as telephone cableNo
Core identification according to HD 308 S2No
Suitable for use as security alarm cableNo
Flame retardant according to IEC 60332-3-24 (Cat C)No
Max. tensile strength during installation0.0115kN
Suitable as signalling cableYes
Flame retardant according to IEC 60332-3-23 (Cat B)No
Number of sheath layers0
Approved type of underground installationOther
Halogen free according to IEC 60754-3No
Halogen free according to IEC 60754-1No
Circuit integrity according to IEC 60331-23No
Certified for shipboard applicationNo
With rip cordNo
Suitable as computer data cableNo
Flame retardant according to IEC 60332-1-2No
Flame retardant according to IEC 60332-3-21 (Cat A F/R)No
Flame retardant according to IEC 60332-3-25 (Cat D)No
DuplexNo
Compatible with Grade3TV according to XP-C 90-483No
Compatible with Grade2TV according to XP-C 90-483No
Flame retardant according to IEC 60332-3-22 (Cat A)No
