Details
- •Cables
- •Data and communication cable
- •1 KOM
- •EATON
Technical specifications
Conductor materialOther
Core identificationColour
Diameter conductor1.35mm
Material core insulationPolyvinyl chloride (PVC)
Colour outer sheathGreen
CategoryOther
Cable typeOther
UV resistantNo
Screen over stranding elementNone
Nominal cross section conductor0.23mm²
Stranding elementNo
Drain wireNo
Nominal voltage U24V
Number of stranding elements0
Permitted cable outer temperature after assembling without vibration-30 - 105°C
Suitable for underground installationNo
Armouring/reinforcementNone
With rodent protectionNo
Radial water blocking cableNo
Smoke development class according to EN 13501-6None
StrandingOther
Outer diameter approx.17.5mm
Conductor categoryClass 2 = stranded
Permitted cable outer temperature during assembling/handling-10 - 105°C
Halogen free (according to IEC 60754-2)No
Oil resistant (according to EN 60811-404)No
Cable width approx.17.5mm
Longitudinal water blocking cableYes
NVP value66.7%
Protective sheathOther
Number of cores8
Characteristic impedance100Ohm
Conductor surfaceTinned
Cable height approx.22mm
Low smoke (according to IEC 61034-2)No
Reaction-to-fire class according to EN 13501-6None
Screen over strandingNone
Material outer sheathPolyvinyl chloride (PVC)
AWG size24
Euro class flaming droplets/particles according to EN 13501-6None
Min. permitted bending radius, moving application with forced guidance15mm
Suitable as telephone cableNo
Core identification according to HD 308 S2No
Min. permitted bending radius, stationary application/permanent installation7.5mm
Material reinforcementOther
Flame retardant according to IEC 60332-3-23 (Cat B)No
Flame retardant according to IEC 60332-3-22 (Cat A)No
Certified for shipboard applicationNo
Suitable as signalling cableYes
Suitable as computer data cableNo
Flame retardant according to IEC 60332-3-24 (Cat C)No
Euro class acidity according to EN 13501-6None
Approved type of underground installationOther
Min. permitted bending radius, moving application/free movement15mm
Specification material outer sheathOther
Halogen free according to IEC 60754-3No
Halogen free according to IEC 60754-1No
Specification core insulationOther
Flame retardant according to IEC 60332-1-2No
Flame retardant according to IEC 60332-3-25 (Cat D)No
Cable geometryFlat
Max. tensile strength during installation0.0115kN
Flame retardant according to IEC 60332-3-21 (Cat A F/R)No
Compatible with Grade2TV according to XP-C 90-483No
Number of sheath layers0
DuplexNo
With rip cordNo
Suitable for use as security alarm cableNo
Circuit integrity according to IEC 60331-23No
Compatible with Grade3TV according to XP-C 90-483No
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
SWD4-5LF8-24-2S
