Details
- •Cables
- •Data and communication cable
- •1 KOM
- •EATON
Technical specifications
Drain wireNo
Material core insulationOther
Cable typeOther
Core identificationColour
Nominal cross section conductor0.5mm²
Nominal voltage U24V
UV resistantYes
Stranding elementPairs
Conductor categoryClass 2 = stranded
CategoryOther
Permitted cable outer temperature after assembling without vibration-20 - 80°C
Colour outer sheathGreen
Number of stranding elements4
With rodent protectionNo
Diameter conductor1.5mm
Material outer sheathPolyvinyl chloride (PVC)
Low smoke (according to IEC 61034-2)No
Protective sheathOther
Characteristic impedance100Ohm
Conductor materialOther
Number of cores8
Screen over stranding elementFoil
Armouring/reinforcementNone
StrandingBundle
Permitted cable outer temperature during assembling/handling-10 - 80°C
Cable height approx.100mm
NVP value66.5%
Outer diameter approx.8.2mm
Suitable for underground installationNo
Cable width approx.8.2mm
Screen over strandingNone
Halogen free (according to IEC 60754-2)No
Flame retardant according to IEC 60332-3-21 (Cat A F/R)No
Oil resistant (according to EN 60811-404)Yes
AWG size20
Reaction-to-fire class according to EN 13501-6None
Certified for shipboard applicationNo
Euro class flaming droplets/particles according to EN 13501-6None
Suitable as telephone cableNo
Suitable as computer data cableNo
Longitudinal water blocking cableNo
Suitable as signalling cableYes
Radial water blocking cableNo
Specification material outer sheathPolypropylene (PP)
Cable geometryRound
Material reinforcementOther
Flame retardant according to IEC 60332-1-2No
Approved type of underground installationOther
Conductor surfaceBare
Min. permitted bending radius, moving application/free movement120mm
Euro class acidity according to EN 13501-6None
Specification core insulationOther
Min. permitted bending radius, stationary application/permanent installation120mm
Core identification according to HD 308 S2No
Flame retardant according to IEC 60332-3-22 (Cat A)No
Smoke development class according to EN 13501-6None
Min. permitted bending radius, moving application with forced guidance120mm
Halogen free according to IEC 60754-1No
DuplexNo
Flame retardant according to IEC 60332-3-25 (Cat D)No
Compatible with Grade2TV according to XP-C 90-483No
Circuit integrity according to IEC 60331-23No
Flame retardant according to IEC 60332-3-24 (Cat C)No
Number of sheath layers0
Halogen free according to IEC 60754-3No
Compatible with Grade3TV according to XP-C 90-483No
Flame retardant according to IEC 60332-3-23 (Cat B)No
Suitable for use as security alarm cableNo
With rip cordNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
SWD4-50LR8-24
