Details
- •Programmable logic controllers PLC
- •Logic module
- •1 KOM
- •EATON
Technical specifications
Width108mm
Height90mm
With time switch clockYes
ExpandableYes
Switching current8A
Power consumption6W
Number of digital inputs14
Number of digital outputs5
With displayYes
Suitable for safety functionsYes
Number of analogue outputs4
Number of HW-interfaces industrial Ethernet0
Number of HW-interfaces RS-2321
Number of analogue inputs0
Voltage type of supply voltageDC
Supporting protocol for LONNo
Number of HW-interfaces RS-4220
Number of HW-interfaces RS-4850
Number of HW-interfaces parallel0
Number of HW-interfaces serial TTY0
Number of HW-interfaces other3
Number of HW-interfaces USB0
Depth72mm
Rail mounting possibleYes
Appendant operation agent (Ex ia)No
Supporting protocol for ModbusNo
Supporting protocol for DeviceNetNo
RedundancyYes
Supporting protocol for Data-HighwayNo
Supporting protocol for other bus systemsYes
Supporting protocol for INTERBUSNo
Explosion safety category for dustNone
Supporting protocol for PROFIBUSNo
Explosion safety category for gasNone
Supporting protocol for CANNo
With optical interfaceNo
With relay outputYes
Supporting protocol for SUCONETNo
Supporting protocol for ASINo
Supporting protocol for KNXNo
Number of HW-interfaces Wireless0
Number of interfaces PROFINET0
Supporting protocol for SERCOSNo
Front built-in possibleNo
Degree of protection (IP)IP20
Supporting protocol for INTERBUS-SafetyNo
Appendant operation agent (Ex ib)No
Supporting protocol for TCP/IPNo
Expansion deviceNo
Performance level according to EN ISO 13849-1Level e
Radio standard BluetoothNo
Supporting protocol for SafetyBUS pNo
Radio standard Wi-Fi 802.11No
Supply voltage DC20.4 - 28.8V
Supply voltage AC 60 Hz0 - 0V
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for PROFINET CBANo
Supporting protocol for PROFIsafeNo
Rack-assembly possibleNo
Supporting protocol for PROFINET IONo
Supporting protocol for EtherNet/IPNo
Basic deviceYes
Supporting protocol for AS-Interface Safety at WorkNo
Wall mounting/direct mountingYes
Radio standard GPRSNo
Supporting protocol for Foundation FieldbusNo
Radio standard UMTSNo
Radio standard GSMNo
Certified for UL hazardous location class INo
Supporting protocol for EtherCATNo
SIL according to IEC 615083
Supply voltage AC 50 Hz0 - 0V
IO link masterNo
Certified for UL hazardous location group D (propane)No
Certified for UL hazardous location division 2No
Certified for UL hazardous location division 1No
Certified for UL hazardous location class IIINo
Certified for UL hazardous location group C (ethylene)No
Certified for UL hazardous location group B (hydrogen)No
Certified for UL hazardous location group A (acetylene)No
Certified for UL hazardous location group F (carbonaceous dusts)No
Certified for UL hazardous location group E (metal dusts)No
Certified for UL hazardous location group G (non-conductive dusts)No
Certified for UL hazardous location class IINo
