Details
- •Low-voltage industrial components
- •Power contactor, AC switching
- •1 KOM
- •EATON
Technical specifications
Width45mm
Height85mm
Rated operation current Ie at AC-1, 400 V45A
Modular versionNo
Number of normally open contacts as main contact3
Number of normally closed contacts as main contact0
Number of auxiliary contacts as normally open contact1
Depth97mm
Number of auxiliary contacts as normally closed contact0
Rated operation power at AC-3, 400 V15kW
Rated operation current Ie at AC-3, 400 V32A
Rated control supply voltage Us at AC 50HZ190 - 240V
Rated operation power at AC-4, 400 V7kW
Rated control supply voltage Us at AC 60HZ190 - 240V
Rated control supply voltage Us at DC0 - 0V
Type of electrical connection of main circuitScrew connection
Operating voltage at AC 60 Hz230 - 690V
Rated operation current Ie at AC-4, 400 V15A
Voltage type for actuatingAC
Operating voltage at AC 50 Hz230 - 690V
Rated operation power NEMA14.9kW
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
DILMF32-10(RAC240)
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power contactor, AC switching
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Width
45mm
Height
85mm
Rated operation current Ie at AC-1, 400 V
45A
Modular version
Number of normally open contacts as main contact
3
Number of normally closed contacts as main contact
0
Number of auxiliary contacts as normally open contact
1
Depth
97mm
Number of auxiliary contacts as normally closed contact
0
Rated operation power at AC-3, 400 V
15kW
Rated operation current Ie at AC-3, 400 V
32A
Rated control supply voltage Us at AC 50HZ
190 .. 240V
Rated operation power at AC-4, 400 V
7kW
Rated control supply voltage Us at AC 60HZ
190 .. 240V
Rated control supply voltage Us at DC
0 .. 0V
Type of electrical connection of main circuit
Screw connection
Operating voltage at AC 60 Hz
230 .. 690V
Rated operation current Ie at AC-4, 400 V
15A
Voltage type for actuating
AC
Operating voltage at AC 50 Hz
230 .. 690V
Rated operation power NEMA
14.9kW
