E56BDL70UAD01
Code: 1201534
ManufacturerEaton
Catalog number136236
TypeE56BDL70UAD01
CategoryInductive proximity switch
EAN code4015081330294
Details
- •Sensors
- •Inductive proximity switch
- •1 KOM
- •EATON
Technical specifications
Number of protected semiconductor outputs0
Material housingPlastic
CascadableNo
Number of semiconductor outputs with signalling function1
Number of contact energized outputs with signalling function0
Number of protected contact energized outputs0
Suitable for safety functionsNo
Coating housingOther
Switching frequency20Hz
Type of electric connectionPlug-in connection
Voltage typeDC
Type of interface for safety communicationNone
Rated control supply voltage Us at DC6 - 48V
Rated control supply voltage Us at AC 60HZ0 - 0V
Mechanical mounting condition for sensorNot flat
Construction type housingCuboid
Explosion safety category for dustNone
Degree of protection (NEMA)4X, 6, 13
Type of interfaceNone
Max. output current at protected output0mA
Type of actuationMetallic Target
Rated control supply voltage Us at AC 50HZ0 - 0V
With monitoring function downstream switching devicesNo
Performance level according to EN ISO 13849-1None
Type of switch functionAnticoincidence
Compression-resistantNo
Explosion safety category for gasNone
SIL according to IEC 61508None
Switching distance70mm
Type of switching outputNPN
Supply voltage6 - 48V
Width sensor110mm
Diameter sensor0mm
Height of sensor41mm
Length of sensor110mm
