Details
- •Sensors
- •Inductive proximity switch
- •1 KOM
- •EATON
Technical specifications
CascadableNo
Voltage typeDC
Suitable for safety functionsNo
Number of protected semiconductor outputs0
Number of contact energized outputs with signalling function0
Number of semiconductor outputs with signalling function1
Coating housingOther
Switching frequency2000Hz
Material housingMetal
Switching distance2mm
Number of protected contact energized outputs0
Rated control supply voltage Us at AC 50HZ0 - 0V
Type of interfaceNone
Construction type housingCylinder plain
Type of switch functionNormally open contact
Type of interface for safety communicationNone
Max. output current at protected output0mA
Type of actuationMetallic Target
Rated control supply voltage Us at AC 60HZ0 - 0V
Explosion safety category for dustNone
Supply voltage10 - 30V
Type of electric connectionCable
Type of switching outputNPN
With monitoring function downstream switching devicesNo
Rated control supply voltage Us at DC10 - 30V
Explosion safety category for gasNone
Mechanical mounting condition for sensorNot flat
Height of sensor0mm
Length of sensor45mm
Performance level according to EN ISO 13849-1None
SIL according to IEC 61508None
Compression-resistantNo
Degree of protection (NEMA)6P
Width sensor0mm
Diameter sensor6mm
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
E57EAL6T110EP
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- Inductive proximity switch
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Cascadable
Voltage type
DC
Suitable for safety functions
Number of protected semiconductor outputs
0
Number of contact energized outputs with signalling function
0
Number of semiconductor outputs with signalling function
1
Coating housing
Other
Switching frequency
2000Hz
Material housing
Metal
Switching distance
2mm
Number of protected contact energized outputs
0
Rated control supply voltage Us at AC 50HZ
0 .. 0V
Type of interface
None
Construction type housing
Cylinder plain
Type of switch function
Normally open contact
Type of interface for safety communication
None
Max. output current at protected output
0mA
Type of actuation
Metallic Target
Rated control supply voltage Us at AC 60HZ
0 .. 0V
Explosion safety category for dust
None
Supply voltage
10 .. 30V
Type of electric connection
Cable
Type of switching output
NPN
With monitoring function downstream switching devices
Rated control supply voltage Us at DC
10 .. 30V
Explosion safety category for gas
None
Mechanical mounting condition for sensor
Not flat
Height of sensor
0mm
Length of sensor
45mm
Performance level according to EN ISO 13849-1
None
SIL according to IEC 61508
None
Compression-resistant
Degree of protection (NEMA)
6P
Width sensor
0mm
Diameter sensor
6mm
