E57EAL8T110SD

Switching distance

1mm

Type of switch function

Normally open contact

Width sensor

0mm

Mechanical mounting condition for sensor

Concise

Height of sensor

0mm

Length of sensor

70mm

Performance level according to EN ISO 13849-1

None

Type of interface for safety communication

None

Type of interface

None

Number of semiconductor outputs with signalling function

1

Number of contact energized outputs with signalling function

0

Cascadable

No

Max. output current at protected output

0mA

SIL according to IEC 61508

None

Construction type housing

Cylinder, screw-thread

Type of electric connection

Plug-in connection

Coating housing

Other

Supply voltage

10 - 30V

Number of protected semiconductor outputs

0

Suitable for safety functions

No

Type of actuation

Metallic Target

Diameter sensor

8mm

Rated control supply voltage Us at AC 60HZ

0 - 0V

Rated control supply voltage Us at DC

10 - 30V

Number of protected contact energized outputs

0

Rated control supply voltage Us at AC 50HZ

0 - 0V

Type of switching output

NPN

Voltage type

DC

With monitoring function downstream switching devices

No

Explosion safety category for dust

None

Degree of protection (NEMA)

6P

Explosion safety category for gas

None

Compression-resistant

No

Switching frequency

2000Hz

Material housing

Metal
