Details
- •Sensors
- •Light scanner with background masking
- •1 KOM
- •EATON
Technical specifications
Max. output current250mA
Adjustment range0 - 100mm
Material housingMetal
Ambient temperature-40 - 55°C
Voltage typeDC
Suitable for safety functionsNo
Number of contact energized outputs with signalling function0
Switching frequency500Hz
With time functionNo
Number of semiconductor outputs with signalling function2
Number of protected semiconductor outputs0
Number of protected contact energized outputs0
Type of interface for safety communicationOther
Type of electric connectionCable
Rated control supply voltage Us at DC10 - 30V
Rated control supply voltage Us at AC 50HZ0 - 0V
Type of switch functionOther
Operation agent-safety classSafety class 2
Type of switching outputNPN
Setting procedureOther
Laser protection classNone
Construction type housingCylinder, screw-thread
Explosion safety category for dustNone
Explosion safety category for gasNone
Max. output current at protected output0mA
Type of lightOther
With restart blockageNo
Type of safety according to IEC 61496-11
Min. reflector distance0mm
Rated control supply voltage Us at AC 60HZ0 - 0V
Pre failure noticeNo
Light dot0mm²
Switching voltage of OSSD at state "high"30V
Transmission range of the safety field0m
Operating distance0 - 0mm
Response time1ms
With monitoring function downstream switching devicesNo
Degree of protection (IP)IP68
Material of cable sheathPolyvinyl chloride (PVC)
With communication interface PROFIBUSNo
With communication interface RS-232No
Analogue output -10 V ... +10 VNo
Height of sensor0mm
Diameter sensor18mm
With communication interface analogueNo
Width sensor0mm
With communication interface SSDNo
Analogue output 0 mA ... 20 mANo
Analogue output 4 mA ... 20 mANo
With communication interface DeviceNetNo
Length of sensor80mm
Analogue output 0 V ... 10 VNo
With communication interface AS-InterfaceNo
With communication interface RS-422No
Material of optical surfaceGlass
With communication interface INTERBUSNo
With communication interface RS-485No
AWG-number22
With communication interface CANOpenNo
With communication interface EthernetNo
Wavelength of the sensor660nm
With communication interface SSINo
With reflectorNo
Sensing modeDark switching
Max. switching distance127mm
With other analogue outputNo
Degree of protection (NEMA)6
TriangulationBackground fade-out
Rated switching distance100mm
