Details
- •Sensors
- •Inductive proximity switch
- •1 KOM
- •EATON
Technical specifications
Voltage typeDC
Number of protected contact energized outputs0
CascadableNo
Number of semiconductor outputs with signalling function1
Type of switching outputPNP
Suitable for safety functionsNo
Material housingMetal
Switching frequency390Hz
Type of electric connectionCable
Switching distance8mm
Type of interface for safety communicationNone
Number of contact energized outputs with signalling function0
Number of protected semiconductor outputs0
Coating housingOther
Type of actuationMetallic Target
Rated control supply voltage Us at AC 60HZ0 - 0V
Rated control supply voltage Us at AC 50HZ0 - 0V
Height of sensor0mm
Explosion safety category for dustNone
Width sensor0mm
Mechanical mounting condition for sensorConcise
Diameter sensor18mm
With monitoring function downstream switching devicesNo
Type of switch functionNormally open contact
Rated control supply voltage Us at DC6 - 48V
Max. output current at protected output0mA
Degree of protection (NEMA)4X, 6, 13
SIL according to IEC 61508None
Supply voltage6 - 48V
Type of interfaceNone
Construction type housingCylinder, screw-thread
Length of sensor64mm
Compression-resistantNo
Explosion safety category for gasNone
Performance level according to EN ISO 13849-1None
