Details
- •Sensors
- •Inductive proximity switch
- •1 KOM
- •EATON
Technical specifications
Material housingMetal
Suitable for safety functionsNo
Switching frequency150Hz
CascadableNo
Switching distance18mm
Voltage typeDC
Number of semiconductor outputs with signalling function1
Coating housingOther
Number of contact energized outputs with signalling function0
Number of protected semiconductor outputs0
Rated control supply voltage Us at DC6 - 48V
Type of electric connectionPlug-in connection
Rated control supply voltage Us at AC 50HZ0 - 0V
Type of interface for safety communicationNone
Type of switch functionNormally open contact
Number of protected contact energized outputs0
Type of switching outputNPN
Rated control supply voltage Us at AC 60HZ0 - 0V
Diameter sensor18mm
Performance level according to EN ISO 13849-1None
Length of sensor69mm
Explosion safety category for dustNone
Explosion safety category for gasNone
Supply voltage6 - 48V
Max. output current at protected output0mA
Type of interfaceNone
Construction type housingCylinder, screw-thread
Mechanical mounting condition for sensorNot flat
With monitoring function downstream switching devicesNo
Type of actuationMetallic Target
Compression-resistantNo
Height of sensor0mm
Width sensor0mm
Degree of protection (NEMA)4X, 6, 13
SIL according to IEC 61508None
