Details
- •Low-voltage industrial components
- •Power contactor, AC switching
- •1 KOM
- •EATON
Technical specifications
Rated operation current Ie at AC-3, 400 V18A
Number of auxiliary contacts as normally open contact3
Number of normally open contacts as main contact3
Rated operation power at AC-3, 400 V7.5kW
Number of normally closed contacts as main contact0
Number of auxiliary contacts as normally closed contact2
Modular versionNo
Rated control supply voltage Us at AC 60HZ240 - 240V
Rated control supply voltage Us at AC 50HZ230 - 230V
Voltage type for actuatingAC
Rated operation current Ie at AC-4, 400 V10A
Rated operation power at AC-4, 400 V4.5kW
Rated operation current Ie at AC-1, 400 V40A
Type of electrical connection of main circuitScrew connection
Rated control supply voltage Us at DC0 - 0V
Rated operation power NEMA7.4kW
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
DILM17-32(230V50HZ,240V60HZ)
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power contactor, AC switching
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Rated operation current Ie at AC-3, 400 V
18A
Number of auxiliary contacts as normally open contact
3
Number of normally open contacts as main contact
3
Rated operation power at AC-3, 400 V
7.5kW
Number of normally closed contacts as main contact
0
Number of auxiliary contacts as normally closed contact
2
Modular version
Rated control supply voltage Us at AC 60HZ
240 .. 240V
Rated control supply voltage Us at AC 50HZ
230 .. 230V
Voltage type for actuating
AC
Rated operation current Ie at AC-4, 400 V
10A
Rated operation power at AC-4, 400 V
4.5kW
Rated operation current Ie at AC-1, 400 V
40A
Type of electrical connection of main circuit
Screw connection
Rated control supply voltage Us at DC
0 .. 0V
Rated operation power NEMA
7.4kW
