Details
- •Sub-floor systems
- •Service box for underfloor installation
- •1 KOM
- •OBO
Technical specifications
Suitable for placing of sealingNo
Built-in opening for floor columnNo
Nominal dimension380mm
Bottom plateNo
Number of appliances to build in1
Degree of protection (IP)IP20
Levelling range62 - 106mm
Suitable for floor duct countersunk (closed)No
Duct height38 - 38mm
Suitable for sub-floor duct overhead closedNo
Decoupling possibility cover from base unitNo
Duct width250 - 250mm
Built-in opening for built-in unitSquare
Min. height finishing layer65mm
Material side wallSteel
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
7400353 | UDSSD 25038 9
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sub-floor systems
- Service box for underfloor installation
- 1 KOM
- OBO
DetailsTechnical specifications
Technical specifications
Suitable for placing of sealing
Built-in opening for floor column
Nominal dimension
380mm
Bottom plate
Number of appliances to build in
1
Degree of protection (IP)
IP20
Levelling range
62 .. 106mm
Suitable for floor duct countersunk (closed)
Duct height
38 .. 38mm
Suitable for sub-floor duct overhead closed
Decoupling possibility cover from base unit
Duct width
250 .. 250mm
Built-in opening for built-in unit
Square
Min. height finishing layer
65mm
Material side wall
Steel
