Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •SOCOMEC
Technical specifications
Number of auxiliary contacts as normally closed contact0
Number of poles3
Number of auxiliary contacts as normally open contact0
Version as emergency stop installationYes
InterlockableYes
Rated operation power at AC-3, 400 V-kW
Number of switches1
Number of auxiliary contacts as change-over contact0
Rated permanent current Iu160A
Degree of protection (IP), front sideIP20
Conditioned rated short-circuit current Iq100kA
Motor drive integratedNo
Type of control elementOther
Colour control elementOther
Version as main switchYes
Version as maintenance-/service switchYes
Rated operation power at AC-23, 400 V80kW
Rated short-time withstand current lcw7kA
Suitable for floor mountingYes
Version as safety switchYes
Rated operating voltage400 - 500V
Type of electrical connection of main circuitBolt connection
Suitable for front mounting 4-holeYes
Suitable for front mounting centreNo
Switching power at 400 V80kW
Motor drive optionalNo
Voltage release optionalNo
Suitable for distribution board installationYes
Rated permanent current at AC-21, 400 V160A
Suitable for intermediate mountingYes
Device constructionBuilt-in device fixed built-in technique
Rated permanent current at AC-23, 400 V160A
Max. rated operation voltage Ue AC800V
Version as reversing switchNo
From same serie
