Details
- •Sensors
- •End switch
- •1 KOM
- •ABB
Technical specifications
Switching functionQuick-break switch
Rated operation current Ie at DC-13, 230 V0.4A
Material housingMetal
Rated operation current Ie at AC-15, 230 V3.1A
Suitable for safety functionsNo
Coating housingPowder coating
Forced openingNo
Construction type housingCuboid
Height of sensor108mm
Width sensor30mm
Number of safety auxiliary contacts0
Number of contacts as normally closed contact1
Type of electric connectionCable entry metrical
Explosion safety category for dustNone
Explosion safety category for gasNone
Type of interface for safety communicationNone
Number of contacts as normally open contact1
Rated operation current Ie at AC-15, 24 V10A
Output electronicNo
Length of sensor44mm
Degree of protection (IP)IP66
Type of interfaceNone
Ambient temperature during operating-25 - 70°C
Rated operation current Ie at AC-15, 125 V5.5A
Diameter sensor0mm
With status indicationNo
Switching function latchingNo
Rated operation current Ie at DC-13, 24 V6A
Rated operation current Ie at DC-13, 125 V0.6A
Type of control elementPlunger
Number of contacts as change-over contact0
Alignment of the control elementOther
Degree of protection (NEMA)4X
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SBV011941R1211 | LS32M41B11
