Details
- •Sensors for automation technology
- •End switch
- •1 KOM
- •ABB
Technical specifications
Number of safety auxiliary contacts0
Diameter sensor0mm
Number of contacts as change-over contact0
Height of sensor93mm
Rated operation current Ie at AC-15, 24 V10A
Switching functionQuick-break switch
Length of sensor33mm
Forced openingNo
Rated operation current Ie at AC-15, 125 V5.5A
Explosion safety category for dustNone
Explosion safety category for gasNone
Rated operation current Ie at AC-15, 230 V3.1A
Construction type housingCuboid
Type of interfaceNone
Rated operation current Ie at DC-13, 125 V0.6A
Rated operation current Ie at DC-13, 24 V6A
Alignment of the control elementOther
Ambient temperature during operating-25 - 70°C
With status indicationNo
Suitable for safety functionsNo
Type of interface for safety communicationNone
Type of electric connectionCable entry metrical
Rated operation current Ie at DC-13, 230 V0.4A
Coating housingPowder coating
Degree of protection (NEMA)4X
Output electronicNo
Switching function latchingNo
Width sensor30mm
Material housingMetal
Number of contacts as normally closed contact1
Number of contacts as normally open contact1
Type of control elementRoller lever
Degree of protection (IP)IP66
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SBV013832R1211 | LS33M32B11
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors for automation technology
- End switch
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Number of safety auxiliary contacts
0
Diameter sensor
0mm
Number of contacts as change-over contact
0
Height of sensor
93mm
Rated operation current Ie at AC-15, 24 V
10A
Switching function
Quick-break switch
Length of sensor
33mm
Forced opening
Rated operation current Ie at AC-15, 125 V
5.5A
Explosion safety category for dust
None
Explosion safety category for gas
None
Rated operation current Ie at AC-15, 230 V
3.1A
Construction type housing
Cuboid
Type of interface
None
Rated operation current Ie at DC-13, 125 V
0.6A
Rated operation current Ie at DC-13, 24 V
6A
Alignment of the control element
Other
Ambient temperature during operating
-25 .. 70°C
With status indication
Suitable for safety functions
Type of interface for safety communication
None
Type of electric connection
Cable entry metrical
Rated operation current Ie at DC-13, 230 V
0.4A
Coating housing
Powder coating
Degree of protection (NEMA)
4X
Output electronic
Switching function latching
Width sensor
30mm
Material housing
Metal
Number of contacts as normally closed contact
1
Number of contacts as normally open contact
1
Type of control element
Roller lever
Degree of protection (IP)
IP66
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
