Details
- •Low-voltage control systems
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Conditioned rated short-circuit current Iq80kA
Version as emergency stop installationNo
Motor drive integratedNo
Type of electrical connection of main circuitBolt connection
Suitable for front mountingNo
Version as safety switchYes
Suitable for floor mountingNo
Rated short-time withstand current lcw14kA
Motor drive optionalNo
Rated operation power at AC-23, 400 V400kW
Suitable for busbar mountingYes
With error protectionNo
Version as main switchYes
Equipped with connectorsYes
Max. rated operation voltage Ue AC690V
Suitable for fusesNH2
Position control elementFront side
Cable entryTop/bottom
Type of control elementDoor coupling rotary drive
Rated permanent current Iu400A
Number of poles3
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022719R0250 | OS400D03P
