Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Version as safety switchYes
Number of poles3
Cable entryOther
Rated operation power at AC-23, 400 V200kW
Version as emergency stop installationNo
Type of electrical connection of main circuitBolt connection
Rated permanent current Iu200A
Rated short-time withstand current lcw8kA
Suitable for fusesNH0
Motor drive integratedNo
Conditioned rated short-circuit current Iq80kA
Suitable for floor mountingNo
Type of control elementLong turning handle
Version as main switchYes
Equipped with connectorsYes
Suitable for front mountingNo
Suitable for busbar mountingYes
Position control elementLeft
Max. rated operation voltage Ue AC1000V
With error protectionNo
Motor drive optionalNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022749R8710 | OS200D03N3P
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Version as safety switch
Number of poles
3
Cable entry
Other
Rated operation power at AC-23, 400 V
200kW
Version as emergency stop installation
Type of electrical connection of main circuit
Bolt connection
Rated permanent current Iu
200A
Rated short-time withstand current lcw
8kA
Suitable for fuses
NH0
Motor drive integrated
Conditioned rated short-circuit current Iq
80kA
Suitable for floor mounting
Type of control element
Long turning handle
Version as main switch
Equipped with connectors
Suitable for front mounting
Suitable for busbar mounting
Position control element
Left
Max. rated operation voltage Ue AC
1000V
With error protection
Motor drive optional
