Details
- •Low-voltage control systems
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Cable entryOther
Motor drive integratedNo
Conditioned rated short-circuit current Iq80kA
Suitable for fusesShape B1-B3
Suitable for floor mountingNo
Type of control elementLong turning handle
Version as main switchYes
Suitable for front mountingNo
Version as emergency stop installationNo
Version as safety switchYes
Type of electrical connection of main circuitBolt connection
Motor drive optionalNo
Rated short-time withstand current lcw8kA
Equipped with connectorsYes
With error protectionNo
Suitable for busbar mountingYes
Position control elementLeft
Rated operation power at AC-23, 400 V200kW
Degree of protection (IP), front sideIP65
Number of poles3
Rated permanent current Iu200A
Max. rated operation voltage Ue AC690V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022750R0620 | OS200B03N3P
