Details
- •Low-voltage control systems
- •Switch disconnector (AC)
- •1 KOM
- •ABB
Technical specifications
Rated operation power at AC-3, 400 V-kW
Degree of protection (IP), front sideOther
Number of auxiliary contacts as change-over contact0
Type of control elementNone
Suitable for floor mountingNo
Version as emergency stop installationNo
Number of auxiliary contacts as normally closed contact0
Rated operation power at AC-23, 400 V355kW
InterlockableNo
Suitable for front mounting centreNo
Conditioned rated short-circuit current Iq-kA
Rated short-time withstand current lcw20kA
Rated operating voltage1000 - 1000V
Suitable for front mounting 4-holeNo
Number of auxiliary contacts as normally open contact0
Motor drive optionalNo
Switching power at 400 V355kW
Version as reversing switchNo
Degree of protection (NEMA)1
Voltage release optionalNo
Suitable for distribution board installationYes
Suitable for intermediate mountingNo
Rated permanent current at AC-23, 400 V630A
Number of poles4
Device constructionBuilt-in device fixed built-in technique
Rated permanent current at AC-21, 400 V630A
Rated permanent current Iu630A
Max. rated operation voltage Ue AC1000V
Suitable for floor mountingYes
Type of electrical connection of main circuitBolt connection
Motor drive integratedNo
Number of switches1
Version as safety switchYes
Version as maintenance-/service switchYes
Version as main switchYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022776R3390 | OT630E04
