Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Rated operation power at AC-23, 400 V630kW
Rated permanent current Iu570A
With error protectionNo
Rated short-time withstand current lcw18kA
Cable entryOther
Max. rated operation voltage Ue AC1000V
Conditioned rated short-circuit current Iq80kA
Version as emergency stop installationNo
Type of electrical connection of main circuitBolt connection
Suitable for busbar mountingYes
Type of control elementShort thumb-grip
Motor drive integratedNo
Number of poles4
Suitable for fusesNH3
Suitable for front mountingNo
Motor drive optionalNo
Version as safety switchYes
Position control elementFront side
Version as main switchYes
Equipped with connectorsYes
Suitable for floor mountingNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022826R1580 | OS630D22F
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Rated operation power at AC-23, 400 V
630kW
Rated permanent current Iu
570A
With error protection
Rated short-time withstand current lcw
18kA
Cable entry
Other
Max. rated operation voltage Ue AC
1000V
Conditioned rated short-circuit current Iq
80kA
Version as emergency stop installation
Type of electrical connection of main circuit
Bolt connection
Suitable for busbar mounting
Type of control element
Short thumb-grip
Motor drive integrated
Number of poles
4
Suitable for fuses
NH3
Suitable for front mounting
Motor drive optional
Version as safety switch
Position control element
Front side
Version as main switch
Equipped with connectors
Suitable for floor mounting
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
