Details
- •Low-voltage control systems
- •Switch disconnector (AC)
- •1 KOM
- •ABB
Technical specifications
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Rated operation power at AC-3, 400 V-kW
Version as maintenance-/service switchYes
Rated operating voltage750 - 750V
InterlockableNo
Number of switches-
Number of auxiliary contacts as change-over contact0
Degree of protection (IP), front sideIP20
Type of electrical connection of main circuitScrew connection
Motor drive integratedNo
Version as safety switchNo
Type of control elementShort thumb-grip
Suitable for floor mountingNo
Rated operation power at AC-23, 400 V37kW
Conditioned rated short-circuit current Iq-kA
Rated short-time withstand current lcw2.5kA
Suitable for distribution board installationYes
Suitable for front mounting centreNo
Motor drive optionalNo
Suitable for intermediate mountingNo
Suitable for front mounting 4-holeNo
Version as reversing switchNo
Voltage release optionalNo
Switching power at 400 V37kW
Rated permanent current at AC-21, 400 V100A
Degree of protection (NEMA)1
Material housingPlastic
Max. rated operation voltage Ue AC690V
Number of poles4
Device constructionBuilt-in device fixed built-in technique
Rated permanent current Iu115A
Version as main switchYes
Colour housingGrey
Rated permanent current at AC-23, 400 V80A
Version as emergency stop installationYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA105018R1001 | OT100F4N2
