Details
- •Low-voltage control systems
- •Switch disconnector (AC)
- •1 KOM
- •ABB
Technical specifications
Number of auxiliary contacts as normally open contact0
Rated operation power at AC-3, 400 V-kW
Rated operating voltage750 - 750V
Number of auxiliary contacts as normally closed contact0
Conditioned rated short-circuit current Iq-kA
Number of switches-
Number of auxiliary contacts as change-over contact0
Version as emergency stop installationNo
Motor drive integratedNo
Type of control elementShort thumb-grip
Version as main switchYes
Rated short-time withstand current lcw2.5kA
Version as safety switchNo
Suitable for front mounting 4-holeNo
Version as maintenance-/service switchYes
Suitable for front mounting centreNo
Suitable for floor mountingNo
Suitable for intermediate mountingNo
Voltage release optionalNo
Motor drive optionalNo
Version as reversing switchNo
InterlockableNo
Degree of protection (NEMA)1
Device constructionBuilt-in device fixed built-in technique
Switching power at 400 V37kW
Rated permanent current at AC-21, 400 V63A
Number of poles3
Rated permanent current at AC-23, 400 V60A
Rated operation power at AC-23, 400 V30kW
Rated permanent current Iu63A
Degree of protection (IP), front sideIP20
Material housingPlastic
Max. rated operation voltage Ue AC690V
Type of electrical connection of main circuitScrew connection
Colour control elementBlack
Suitable for distribution board installationYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA105076R1001 | OT60F3
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage control systems
- Switch disconnector (AC)
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Number of auxiliary contacts as normally open contact
0
Rated operation power at AC-3, 400 V
-kW
Rated operating voltage
750 .. 750V
Number of auxiliary contacts as normally closed contact
0
Conditioned rated short-circuit current Iq
-kA
Number of switches
-
Number of auxiliary contacts as change-over contact
0
Version as emergency stop installation
Motor drive integrated
Type of control element
Short thumb-grip
Version as main switch
Rated short-time withstand current lcw
2.5kA
Version as safety switch
Suitable for front mounting 4-hole
Version as maintenance-/service switch
Suitable for front mounting centre
Suitable for floor mounting
Suitable for intermediate mounting
Voltage release optional
Motor drive optional
Version as reversing switch
Interlockable
Degree of protection (NEMA)
1
Device construction
Built-in device fixed built-in technique
Switching power at 400 V
37kW
Rated permanent current at AC-21, 400 V
63A
Number of poles
3
Rated permanent current at AC-23, 400 V
60A
Rated operation power at AC-23, 400 V
30kW
Rated permanent current Iu
63A
Degree of protection (IP), front side
IP20
Material housing
Plastic
Max. rated operation voltage Ue AC
690V
Type of electrical connection of main circuit
Screw connection
Colour control element
Black
Suitable for distribution board installation
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
