Details
- •RASTAVNA SKLOPKA OT, TROPOLNA, 2500/-(AC22A/AC23A)
- •Low-voltage control systems
- •Switch disconnector (AC)
- •Minimum order quantity: 1 pcs
- •ABB
Technical specifications
Width500.5mm
Height376.5mm
Number of auxiliary contacts as normally open contact0
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally closed contact0
Depth145.5mm
Degree of protection (IP), front sideOther
Width in number of modular spacings-
Conditioned rated short-circuit current Iq-kA
Rated operating voltage1000 - 1000V
Motor drive integratedNo
Type of control elementLong turning handle
Number of switches-
Suitable for floor mountingNo
Version as main switchYes
Number of auxiliary contacts as change-over contact0
Rated operation power at AC-23, 400 V-kW
Colour control elementBlack
Voltage release optionalNo
Version as emergency stop installationNo
Motor drive optionalNo
Suitable for intermediate mountingNo
Version as maintenance-/service switchYes
Suitable for distribution board installationYes
Rated short-time withstand current lcw55kA
Type of electrical connection of main circuitBolt connection
Suitable for front mounting 4-holeNo
InterlockableYes
Suitable for front mounting centreNo
Version as safety switchNo
Version as reversing switchNo
Switching power at 400 V-kW
Device constructionBuilt-in device fixed built-in technique
Degree of protection (NEMA)1
Rated permanent current at AC-23, 400 V-A
With pre-assembled cablingNo
Material housingPlastic
Rated permanent current at AC-21, 400 V2500A
Colour housingGrey
Rated permanent current Iu2500A
Number of poles3
Max. rated operation voltage Ue AC1000V
