Technical specifications
Suitable for fusesNH3
Type of control elementShort thumb-grip
Rated permanent current Iu720A
Motor drive integratedNo
Version as safety switchYes
Cable entryOther
Version as emergency stop installationNo
Type of electrical connection of main circuitBolt connection
Conditioned rated short-circuit current Iq80kA
Rated short-time withstand current lcw18kA
Number of poles3
Rated operation power at AC-23, 400 V710kW
Version as main switchYes
Suitable for floor mountingNo
Suitable for busbar mountingYes
Max. rated operation voltage Ue AC1000V
Suitable for front mountingNo
With error protectionNo
Motor drive optionalNo
Equipped with connectorsYes
Position control elementLeft
