Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •ABB
Technical specifications
Number of auxiliary contacts as normally closed contact0
Degree of protection (IP)IP20
Number of auxiliary contacts as change-over contact0
Adjustment range short-term delayed short-circuit release480.0 - 8000A
Overload release current setting320.0 - 800A
Type of control elementPush button
Number of poles4
Motor drive integratedNo
Type of electrical connection of main circuitBolt connection
With switched-off indicatorNo
Number of auxiliary contacts as normally open contact0
Adjustment range undelayed short-circuit release1200.0 - 9600A
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz50kA
Rated permanent current Iu800A
Rated voltage690 - 690V
Position of connection for main current circuitFront side
Integrated earth fault protectionNo
Suitable for DIN rail (top hat rail) mountingNo
DIN rail (top hat rail) mounting optionalNo
Complete device with protection unitYes
Motor drive optionalYes
With under voltage releaseNo
Device constructionBuilt-in device fixed built-in technique
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SDA061990R1 | T7S 800 PR232/P LSI IN=800A 4P F F M
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power circuit-breaker for trafo/generator/installation protection
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Number of auxiliary contacts as normally closed contact
0
Degree of protection (IP)
IP20
Number of auxiliary contacts as change-over contact
0
Adjustment range short-term delayed short-circuit release
480.0 .. 8000A
Overload release current setting
320.0 .. 800A
Type of control element
Push button
Number of poles
4
Motor drive integrated
Type of electrical connection of main circuit
Bolt connection
With switched-off indicator
Number of auxiliary contacts as normally open contact
0
Adjustment range undelayed short-circuit release
1200.0 .. 9600A
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
50kA
Rated permanent current Iu
800A
Rated voltage
690 .. 690V
Position of connection for main current circuit
Front side
Integrated earth fault protection
Suitable for DIN rail (top hat rail) mounting
DIN rail (top hat rail) mounting optional
Complete device with protection unit
Motor drive optional
With under voltage release
Device construction
Built-in device fixed built-in technique
