Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Rated permanent current Iu125A
Suitable for fusesNH000, NH00
Version as main switchYes
Degree of protection (IP), front sideIP30
Version as emergency stop installationNo
Motor drive integratedNo
Version as safety switchYes
Cable entryOther
Number of poles3
Type of control elementOther
Conditioned rated short-circuit current Iq50kA
Rated operation power at AC-23, 400 V-kW
Type of electrical connection of main circuitCable clamp
Suitable for floor mountingNo
Suitable for front mountingNo
Suitable for busbar mountingYes
Rated short-time withstand current lcw-kA
Motor drive optionalNo
Position control elementFront side
With error protectionNo
Max. rated operation voltage Ue AC690V
Equipped with connectorsYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SEP101916R0001 | XLP00-A60/60-B-3BC
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Rated permanent current Iu
125A
Suitable for fuses
NH000, NH00
Version as main switch
Degree of protection (IP), front side
IP30
Version as emergency stop installation
Motor drive integrated
Version as safety switch
Cable entry
Other
Number of poles
3
Type of control element
Other
Conditioned rated short-circuit current Iq
50kA
Rated operation power at AC-23, 400 V
-kW
Type of electrical connection of main circuit
Cable clamp
Suitable for floor mounting
Suitable for front mounting
Suitable for busbar mounting
Rated short-time withstand current lcw
-kA
Motor drive optional
Position control element
Front side
With error protection
Max. rated operation voltage Ue AC
690V
Equipped with connectors
