1SVR405611R4100 | CR-M012DC2L
Code: 1543081
ManufacturerABB
Catalog number1SVR405611R4100
TypeCR-M012DC2L
CategorySwitching relay
EAN code4013614497292
Details
- •Relays
- •Switching relay
- •1 KOM
- •ABB
Technical specifications
Type of switch contactSingle contact
Drive, switching attitudeMono stable
Complete with socketNo
Height35.6mm
With detachable clampsNo
Drive, polarizationPolarized
Max. starting current-A
With forced-guided contactsNo
Depth27.5mm
Rated control supply voltage Us at AC 60HZ- - -V
Degree of protection (IP)IP40
Rated control supply voltage Us at DC12 - 12V
Relay technology category according to IEC 61810-7RT I
Operating voltage at AC 60 Hz250 - 250V
Operating voltage at AC 50 Hz250 - 250V
Material contactSilver nickel (AgNi)
Material of contact surfaceOther
Operating voltage at DC- - -V
Voltage type (operating voltage)AC/DC
Type of electric connectionPlug-in connection
With LED indicationYes
Number of contacts as normally closed contact0
Width21.2mm
Number of contacts as normally open contact0
Nominal current12A
Rated control supply voltage Us at AC 50HZ- - -V
Voltage type for actuatingDC
Number of contacts as change-over contact2
