Details
- •Relays
- •Switching relay
- •1 KOM
- •ABB
Technical specifications
Type of electric connectionPlug-in connection
Nominal current10A
With forced-guided contactsNo
Complete with socketNo
Type of switch contactSingle contact
Depth35mm
Max. starting current-A
Width35mm
With detachable clampsNo
Height54.4mm
Drive, polarizationPolarized
Drive, switching attitudeMono stable
Rated control supply voltage Us at AC 60HZ24 - 24V
Voltage type (operating voltage)AC/DC
Rated control supply voltage Us at DC- - -V
Degree of protection (IP)IP40
With LED indicationYes
Rated control supply voltage Us at AC 50HZ24 - 24V
Material of contact surfaceOther
Operating voltage at AC 50 Hz250 - 250V
Operating voltage at AC 60 Hz250 - 250V
Number of contacts as normally closed contact0
Voltage type for actuatingAC
Material contactSilver nickel (AgNi)
Operating voltage at DC- - -V
Number of contacts as normally open contact0
Number of contacts as change-over contact2
Relay technology category according to IEC 61810-7RT I
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SVR405621R0100 | CR-U024AC2L
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Relays
- Switching relay
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Type of electric connection
Plug-in connection
Nominal current
10A
With forced-guided contacts
Complete with socket
Type of switch contact
Single contact
Depth
35mm
Max. starting current
-A
Width
35mm
With detachable clamps
Height
54.4mm
Drive, polarization
Polarized
Drive, switching attitude
Mono stable
Rated control supply voltage Us at AC 60HZ
24 .. 24V
Voltage type (operating voltage)
AC/DC
Rated control supply voltage Us at DC
- .. -V
Degree of protection (IP)
IP40
With LED indication
Rated control supply voltage Us at AC 50HZ
24 .. 24V
Material of contact surface
Other
Operating voltage at AC 50 Hz
250 .. 250V
Operating voltage at AC 60 Hz
250 .. 250V
Number of contacts as normally closed contact
0
Voltage type for actuating
AC
Material contact
Silver nickel (AgNi)
Operating voltage at DC
- .. -V
Number of contacts as normally open contact
0
Number of contacts as change-over contact
2
Relay technology category according to IEC 61810-7
RT I
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
