Details
- •Relays
- •Switching relay
- •1 KOM
- •ABB
Technical specifications
With detachable clampsNo
Nominal current10A
Rated control supply voltage Us at AC 60HZ- - -V
Max. starting current-A
Depth35mm
With LED indicationYes
Drive, polarizationPolarized
Material of contact surfaceOther
Drive, switching attitudeMono stable
Height54.4mm
Rated control supply voltage Us at AC 50HZ- - -V
Degree of protection (IP)IP40
With forced-guided contactsNo
Complete with socketNo
Material contactSilver nickel (AgNi)
Rated control supply voltage Us at DC220 - 220V
Voltage type (operating voltage)AC/DC
Type of switch contactSingle contact
Width35mm
Type of electric connectionPlug-in connection
Operating voltage at AC 60 Hz250 - 250V
Operating voltage at AC 50 Hz250 - 250V
Operating voltage at DC- - -V
Voltage type for actuatingDC
Number of contacts as change-over contact2
Number of contacts as normally open contact0
Number of contacts as normally closed contact0
Relay technology category according to IEC 61810-7RT I
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SVR405621R9100 | CR-U220DC2L
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Relays
- Switching relay
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
With detachable clamps
Nominal current
10A
Rated control supply voltage Us at AC 60HZ
- .. -V
Max. starting current
-A
Depth
35mm
With LED indication
Drive, polarization
Polarized
Material of contact surface
Other
Drive, switching attitude
Mono stable
Height
54.4mm
Rated control supply voltage Us at AC 50HZ
- .. -V
Degree of protection (IP)
IP40
With forced-guided contacts
Complete with socket
Material contact
Silver nickel (AgNi)
Rated control supply voltage Us at DC
220 .. 220V
Voltage type (operating voltage)
AC/DC
Type of switch contact
Single contact
Width
35mm
Type of electric connection
Plug-in connection
Operating voltage at AC 60 Hz
250 .. 250V
Operating voltage at AC 50 Hz
250 .. 250V
Operating voltage at DC
- .. -V
Voltage type for actuating
DC
Number of contacts as change-over contact
2
Number of contacts as normally open contact
0
Number of contacts as normally closed contact
0
Relay technology category according to IEC 61810-7
RT I
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
