Details
- •Low-voltage switchgear and control gear (automation)
- •DC-power supply
- •1 KOM
- •ABB
Technical specifications
Width175mm
Suitable for safety functionsNo
Short-circuit-proofYes
Type of electric connectionScrew connection
Built-in height123.6mm
Voltage type of supply voltageAC/DC
Wall mounting possibleNo
1st secondary output voltage24 - 24V
3rd secondary output voltage0 - 0V
Rated supply voltage at AC 50 Hz90 - 264V
Secondary voltage adjustableNo
Depth123.6mm
Width in number of modular spacings-
Power consumption539VA
Direct mounting possibleNo
2nd secondary output voltage0 - 0V
Rated supply voltage at AC 60 Hz90 - 264V
Degree of protection (IP)IP20
Built-in width175mm
Height123.6mm
Rated supply voltage at DC120 - 375V
Performance level according to EN ISO 13849-1None
Max. output current 20A
Max. output current 30A
Nominal value output current 30A
Degree of protection (NEMA)1
Nominal value output voltage 30V
Nominal value output voltage 20V
Nominal value output current 20A
SIL according to IEC 61508None
Max. output current 120A
Nominal value output voltage 124V
Nominal value output current 120A
StabilizedYes
Modular versionYes
Rail mounting possibleYes
Power output480W
Output voltage stabilizedYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SVR427036R0000 | CP-E 24/20.0
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage switchgear and control gear (automation)
- DC-power supply
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Width
175mm
Suitable for safety functions
Short-circuit-proof
Type of electric connection
Screw connection
Built-in height
123.6mm
Voltage type of supply voltage
AC/DC
Wall mounting possible
1st secondary output voltage
24 .. 24V
3rd secondary output voltage
0 .. 0V
Rated supply voltage at AC 50 Hz
90 .. 264V
Secondary voltage adjustable
Depth
123.6mm
Width in number of modular spacings
-
Power consumption
539VA
Direct mounting possible
2nd secondary output voltage
0 .. 0V
Rated supply voltage at AC 60 Hz
90 .. 264V
Degree of protection (IP)
IP20
Built-in width
175mm
Height
123.6mm
Rated supply voltage at DC
120 .. 375V
Performance level according to EN ISO 13849-1
None
Max. output current 2
0A
Max. output current 3
0A
Nominal value output current 3
0A
Degree of protection (NEMA)
1
Nominal value output voltage 3
0V
Nominal value output voltage 2
0V
Nominal value output current 2
0A
SIL according to IEC 61508
None
Max. output current 1
20A
Nominal value output voltage 1
24V
Nominal value output current 1
20A
Stabilized
Modular version
Rail mounting possible
Power output
480W
Output voltage stabilized
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
