Details
- •Relays
- •Current monitoring relay
- •1 KOM
- •ABB
Technical specifications
Number of contacts as normally closed contact-
Number of contacts as normally open contact-
Single-phase under current possibleYes
Type of electric connectionScrew connection
Single-phase hysteresis possibleYes
Contains function DC-voltage over currentYes
Three-phase under current possibleNo
Contains function DC-voltage under currentYes
Rated control supply voltage Us at DC24 - 240V
Rated control supply voltage Us at AC 60HZ24 - 240V
Rated control supply voltage Us at AC 50HZ24 - 240V
Three-phase over current possibleNo
Single-phase over current possibleYes
Voltage type for actuatingAC/DC
With detachable clampsNo
Min. adjustable delay-on energization time0.1s
Three-phase hysteresis possibleNo
Current measuring range0.1 - 1A
Min. adjustable off-delay time0.1s
Max. permitted delay-on energization time30s
External current transformerNo
Height85.6mm
Width22.5mm
Max. permitted off-delay time30s
Depth103.7mm
Function DC-current hysteresisYes
Number of contacts as change-over contact2
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SVR730840R0600 | CM-SRS.M1S
Details
- Relays
- Current monitoring relay
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Number of contacts as normally closed contact
-
Number of contacts as normally open contact
-
Single-phase under current possible
Type of electric connection
Screw connection
Single-phase hysteresis possible
Contains function DC-voltage over current
Three-phase under current possible
Contains function DC-voltage under current
Rated control supply voltage Us at DC
24 .. 240V
Rated control supply voltage Us at AC 60HZ
24 .. 240V
Rated control supply voltage Us at AC 50HZ
24 .. 240V
Three-phase over current possible
Single-phase over current possible
Voltage type for actuating
AC/DC
With detachable clamps
Min. adjustable delay-on energization time
0.1s
Three-phase hysteresis possible
Current measuring range
0.1 .. 1A
Min. adjustable off-delay time
0.1s
Max. permitted delay-on energization time
30s
External current transformer
Height
85.6mm
Width
22.5mm
Max. permitted off-delay time
30s
Depth
103.7mm
Function DC-current hysteresis
Number of contacts as change-over contact
2
